21.9% high-efficiency N-type shingled solar module ORY440M-46S (440W, 1812x1096x30mm, 21.2kg) black frame, CE/TUV certified, 25-year warranty
Product Information
| Model | ORY440M- 46S |
| Rated Power | 440W |
| Dimension | 1812x1096x30mm |
| Weight | 21.2Kg |
| Cell Type | N Type Shingled |
| Module Color | Black Frame |
| Efficiency | 21.90% |
| Certification | CE/TUV |
| Warranty | 25Years |
Specifications
| Cell Type | Mono-crystalline solar cell | ||||
| Dimension | 1812x1096x30mm | ||||
| Weight | 21.2kg | ||||
| Glass | 3.2mm AR Coating Tempered Glass | ||||
| Frame | Anodized aluminum alloy frame | ||||
| Junction Box | IP68,2 diodes | ||||
| Output Cable | TUV:4mm2/UL-12AWG | ||||
| Packaging | 36pcs/pallet, 924pcs/40'HQ | ||||
| Maximum Power(Pmax) | 420W | 425W | 430W | 435W | 440W |
| Maximum Power Voltage(Vmp) | 34.50V | 34.60V | 34.70V | 34.80V | 34.90V |
| Maximum Power Current(Imp) | 12.19A | 12.30A | 12.39A | 12.50A | 12.60A |
| Open-circuit Voltage(Voc) | 41.60V | 41.70V | 41.80V | 41.90V | 42.00V |
| Short-circuit Current(lsc) | 13.92A | 13.03A | 13.14A | 13.26A | 13.37A |
| Module Efficiency(%) | 22.20% | 21.10% | 21.40% | 21.70% | 21.90% |
