SRNE ASP48 series 14-16kW inverters: 230Vac, 48Vdc, 300A charging, 2 MPPT, 46.3kg, IP20, 2-year warranty, pure sine wave output.
Product Information
| Model | ASP48140S300-H~ASP48160S300-H |
| Output Voltage | 220V/230V |
| Max Output Power | 14-16KW |
| PV Input Voltage | 12000W + 12000W |
| Battery Voltage | 40-60V |
| Weight | 46.3kg |
| Dimension | 514*804*215mm(W/H/D) |
| Warranty | 5 Years |
Specifications
| Model | ASP48140S300-H | ASP48150S300-H | ASP48160S300-H |
| AC OUTPUT | |||
| Rated Output Power | 14000W | 15000W | 16000W |
| Max. Peak Power | 2 times rated power, 10s | ||
| Max. Apparent Power | 14000VA | 15000VA | 16000VA |
| Rated Output Voltage | 230Vac (L+N+PE) | ||
| Rated Output Current | 60.9Aac | 65.2Aac | 69.6Aac |
| Load Motor Capacity | 9HP | ||
| Rated Frequency | 50/60Hz | ||
| Waveform | Pure sine wave | ||
| Switch Time | 10ms (typical) | ||
| BATTERY | |||
| Battery Type | Li-Ion / Lead-acid / User-defined | ||
| Rated Battery Voltage | 48Vdc | ||
| Battery Volatge Range | 40Vdc~60Vdc | ||
| Max. Grid/Generator Charging Current | 300Adc | 300Adc | 300Adc |
| Max. Charging/Discharging Current | 300Adc | 300Adc | 300Adc |
| SOLAR INPUT | |||
| No. Of MPPT | 2 | ||
| Max. PV Input Power | 12000W + 12000W | ||
| Max. PV Input Current | 36Adc + 36Adc | ||
| PV Short-circuit Current | 50Adc + 50Adc | ||
| PV Start-up Voltage | 90Vdc / 90Vdc | ||
| Max. PV Open-Circuit Voltage | 650Vdc / 650Vdc | ||
| MPPT Operating Voltage Range | 120Vdc~600Vdc / 120Vdc~600Vdc | ||
| GRID/GENERATOR INPUT | |||
| Rated Input Voltage | 230Vac (L+N+PE) | ||
| Input Voltage Range | 90Vac~280Vac | ||
| Rated Input Frequency | 50Hz/60Hz | ||
| Bypass Overload Current (Grid) | 100Aac | ||
| Bypass Overload Current (Generator) | 60.9Aac | 65.2Aac | 69.6Aac |
| EFFICIENCY | |||
| MPPT Tracking Efficiency | >99% | ||
| Max. Inverter Efficiency | 94.3% | ||
| Max. Charging Efficiency | 93.4% | ||
| GENERAL DATA | |||
| Parallel Capacity | 1~6 Units | ||
| Dimension (W*H*D) | 514*804*215mm | Altitude | 2000m |
| Weight | 46.3kg | Cooling Method | Intelligent Air Cooling |
| Protection Degree | IP20 Indoor Only | Warranty | 2 years |
| Temperature | -10~55°C, >45°C Derated | Communication | RS485/CAN/USB/Dry Contact |
| Noise | <60dB | External Module (Optional) | Wi-Fi/4G Stick |
| Certificate | IEC62109-1, IEC62109-2, EN61000-6-1, EN61000-6-3 | ||
| PROTECTION | |||
| Has PV Current Limiting Protection, PV Overvoltage Protection, Night Anti - backcharging Protection, Mains Input Overvoltage Protection, Mains Input Undervoltage Protection, Battery Overvoltage Protection, Battery Undervoltage Protection, Battery Overcurrent Protection, AC Output Short - circuit Protection, Heat Sink Overtemperature Protection, Overload Protection, AC Backfeed Protection, Bypass Overcurrent Protection, Bypass Wiring Error Protection, Arc Fault Protection, Leakage Current Protection, Rapid Shutdown Signal Generator (Optional) | |||
