High-Performance SPE 8000-12000 ES Solar Inverter 12KW 230V Output 21.5kg
Product Information
| Model | S6-EH1P(12-16)K03-NV |
| Output Voltage | 220V/230V |
| Max Output Power | 12KW |
| PV Input Voltage | 550V |
| Battery Voltage | 40-60V |
| Weight | 21.5kg |
| Dimension | 550/465/150mm(W/H/D) |
| Warranty | 5 Years(10 Years Optional) |
Specifications
| Dataset | SPE800ES | SPE1000ES | SPE1200ES |
| Input data(DC) | |||
| Max. recommended PV power (for module STC) | 10000W | 12500W | 15000W |
| Max. DC voltage | 550V | ||
| Start voltage | 120V | ||
| MPP voltage range | 60V~480V | ||
| No. of MPP trackers | 2 | ||
| No. of PV strings per MPP tracker | 1 | ||
| Max. input current per MPP tracker | 27A | ||
| Output data(AC) | |||
| AC nominal power | 8000W | 10000W | 12000W |
| Max. AC apparent power | 8000VA | 10000VA | 12000VA |
| Nominal AC voltage | 230V | ||
| AC grid frequency | 50/60Hz | ||
| Output current | 34.8A | 43.5A | 52.2A |
| Adjustable power factor | 0.8leading...0.8lagging | ||
| THDi | <5% | ||
| Max. conversion efficiency (PV/AC) | 96.5% | ||
| European efficiency @ vn nominal (PV/AC) | 95.5% | ||
| Battery Data(DC) | |||
| Nominal DC voltage | 48V | ||
| Max charging and discharging current | 190A/200A | 220A/240A | 250A/280A |
| Type of battery | Lithium/Lead-acid | ||
| Backup Power(AC) | |||
| AC nominal output power | 8000W | 10000W | 12000W |
| Nominal AC output voltage | 230V | ||
| Nominal AC output frequency | 50/60Hz | ||
| Switch time | <20ms@Single <30ms@Parallel | ||
| Efficiency | |||
| Peak. efficiency | 96.5% | ||
| Peak. efficiency | 95.5% | ||
| General data | |||
| Dimensions (W / H / D) | 550/465/150mm | ||
| Weight | 21.5kg | ||
| Operating temperature range | −10℃ .... +50℃ | ||
| Noise emission (typical) | <75dB | ||
| Self-consumption | < 75W | ||
| Topology | Tranformerless | ||
| Cooling | DC fan | ||
| Protection degree | IP20 | ||
| Relative humidity | 5%~95% non-condensing | ||
| Altitude | <2000m | ||
| Communication | WiFi/4G | ||
