Designed specifically for low-voltage solar power systems, this stable, space-saving wall-mounted design makes it an ideal choice for residential and small-scale commercial energy storage scenarios.
Product Information
| Model | ORY-LV100 |
| Battery Energy Capacity | 5.12/5Kwh |
| Rated Voltage | 51.2V |
| Rated Cell Capacity | 100Ah |
| Application | Low Voltage/Wall Mounted |
| Weight | 52Kg |
| Cycle Times | 6000 Times |
| Certification | CE,UN38.3,MSDS,IEC62619 |
Specifications
| Model | ORY-LV100 |
| POLO-W1 | LFP |
| Cell Capacity | 100AH |
| Battery Module Capacity | 5.12kwh |
| Expandable Capacity | 5.12kwh |
| Nominal Voltage | 51.2V |
| Voltage Range | 42v-58.4v |
| Rated Charge/Discharge Current | 50A/100A @25±2℃ |
| Maximum Charge/Discharge Current | 100A@25±2℃ |
| Working Temperature | -20~55℃ |
| Weight (kg) | 52kg |
| Dimension (mm) | 578.5*458.5*172.4mm |
| Communication Mode | CAN&RS485 |
| Battery Protection | Over-current/Over-voltage/Short circuit/ Under-voltage/Over temperature/Low temperature |
| Warranty | 10 Years |
| Altitude | <2000m |
| Cooling | Natural |
| Cycle Life | ≥6000 |
| IP Rated | IP65 |
| Safety Standrds | CE,UN38.3,MSDS,IEC62619 |
