Designed specifically for medium to large-scale low-voltage solar power systems, it features high energy density, stable charge and discharge performance, and wide temperature adaptability, making it suitable for residential backup power, small-scale commercial energy management, and off-grid solar projects.
Product Information
| Model | ORY-LV200 |
| Product Type | Low-voltage Energy Storage Battery |
| Nominal Voltage | 51.2V |
| Rated Capacity | 280Ah |
| Nominal Energy | 14.336KWh |
| Weight | 127kg |
| Size | 580×750×280mm |
Specifications
| Model | M16S280BL-F |
| Product Type | Low-voltage Energy Storage Battery |
| Nominal Voltage | 51.2V |
| Rated Capacity | 280Ah |
| Charge Voltage | 58.4V |
| Standard Charging Current | 56A |
| Max. Charging Current | 200A |
| Max. Discharging Current | 200A |
| Discharge Cut-off Voltage | 42V |
| Nominal Energy | 14.336KWh |
| Charging Operating Temperature | 0-60°C |
| Discharging Operating Temperature | -20°C-65°C |
| Communication Mode | RS485/CAN |
| Working Humidity | <90%RH |
| Working Altitude | 2000m |
| IP Grade | IP21 |
| Weight | 127kg |
| Size | 580×750×280mm |
