ORY-LV314 LiFePO4 battery: 51.2V 314Ah 16.08KWh, 200A max charge/discharge, -10~60℃, IP21, 121kg, 540×300×910mm, ideal for solar & PV storage.
Product Information
| Model | ORY-LV314 |
| Battery Energy Capacity | 16.08Kwh |
| Rated Voltage | 51.2V |
| Rated Cell Capacity | 314Ah |
| Application | Low Voltage |
| Weight | 131Kg |
| Cycle Times | 6000 Times |
| Certification | CE,UN38.3,MSDS,IEC62619 |
Specifications
| Product Type | M16S314BL-F |
| Nominal Voltage | 51.2V |
| Rated Capacity | 314Ah |
| Charge Voltage | 58.4V |
| Standard Charging Current | 62A |
| Max. Charging Current | 200A |
| Max. Discharging Current | 200A |
| Discharge Cut-off Voltage | 42V |
| Nominal Energy | 16.08KWh. |
| Operating Temp. Charge | 0~50°C |
| Operating Temp. Discharge | -10°C~60°C |
| Communication Mode | RS485\CAN |
| Working Humidity | <90%RH |
| Working Altitude | ≤2000m |
| IP Grade | IP21 |
| Weight | ~121kg |
| Size | 540x300x910mm |
